*Please send message first to check shipping fee.
Monster gravel with a lightsaber
Drop bars, chunky tires, and a carbon fork equals fun all around!
- Aluminium frame
- Kocevlo Carbon fork
- 420mm Gravel Drop bar
- Uno 60mm stem
- L-TWOO GR7 shifter and rear derailleur 10spd
- Tektro Mechanical Calipers dual piston
- SENICX crankset 165mm with GOLDIX 34t
- SUNSHINE 11/50 cassette
- AVP Lightweight Seatpost
- Speedone Soldier Wide Rims 29er with Stainless steel spokes
- Tanke hubs Boost
- Maxxis Ikon 29x2.2
SPECIFICATIONS:
- Relaxed geometry
- Wide tire clearance - Up to 29x2.4” and 27.5x2.6” tires!
- Optimized for use with a 100mm suspension fork
- Lots of mounts for cages and bags
- Butted and bigger tubes for a lighter and firmer ride, even with lots of cargo loaded.
Frame spec and features:
- Alloy 6061 frame and fork
- Boost hub spacing
- Post mount fork brake mounts to accept larger rotors
- Flat mount brake mounts on the frame
- External cable routing for easy maintenance on the road
- Internal dropper post routing
- Internal dynamo wire routing
- Lots of cage and bag mounts plus fender mounts
- BSA threaded bottom bracket
- 31.6 seat post size
- Headset is tapered internal 44/56
Geometry numbers:
PATH X - Small (fits 5’2” - 5’6")
- Seat tube: 45.5cm/ 18"
- Top tube: 53cm
- Effective top tube: 56cm
- Reach: 36cm
- Head tube: 10cm
- Chain stay lenght: 45.5cm
- Wheel base: 109cm
PATH X Medium (fits 5’7” - 6’0”)
- Seat tube: 48cm/19"
- Top tube: 55cm
- Effective top tube: 58.5cm
- Reach: 36.5 cm
- Head tube: 10cm
- Chain stay lenght: 45.5
- Wheel base: 109cm
